[Pilotech] YC-029 10L/H Pilot Scale Spray Dryer : 분무건조기 (Spray Dryer)

Sr.no	Parameter	Pilotech YC-29 Pilot Scale Spray Dryer
1	Power	21000W
2	Voltage	380V,50/60 Hz
3	Atomizer material	SUS 316 Stainless steel
4	Capacity	10 L/H
5	Airflow	3 mᶟ/min
6	max. Input temperature	260⁰C
7	Heater power	15000W
8	Temperature precision	±2⁰C
9	Spray gas	128L/min, 2-5bar
10	Nozzle jet	3MM
11	Nozzle type	Two fluid nozzle
12	Possible particle size range	1-150µm
12	Operation mode	Automatic/Manual
14	Max. Sample feed	10000ml/hr
15	Minimum sample volume	200ml
16	Spray chamber material	SUS 304 stainless steel
17	Cyclone separator material	SUS 304 stainless steel
18	Receiving tank material	SUS 304 stainless steel
19	Body material	SUS304 Stainless steel
20	Seal of cyclone/cylinder	Silicone
21	Deblocking	Automatic
22	Dimensions	172016502550
23	Weight	490KG
24	Display	8-Inch LCD display for Heat, Spray, Pump, Air pressure, de-blocker frequency
25	Inert loop (for organic solvents)	Optional
